V2 Flight Instrument

V2 Flight Instrument

SOLD OUT - DO NOT PLACE ANY ORDERS

£0.00

SOLD OUT – PLEASE CONTACT US FOR MORE INFO :

The V2 Flight Instrument is a true sunlight readable LCD touchscreen PNA and is recommended to be used with LK8000 software available to download from http://lk8000.it/

The LCD screen is enhanced for clear visibility under direct sunlight, not only the brightness but also the screen contrast and anti-reflection properties of the V2 make this unit perfect for aviation use. Compared to other commercial PNAs, the difference is like night and day!

This unit has a mini USB RS232 serial line which can be connected to external instruments. A special cable is required to use this RS232 which can be purchased from http://www.glidertools.com/ or http://www.gliderguider.net/
.

Have a look at what the LK8000 team are writing about the V2:-

.

“We received the very first sample from Vertica a couple of months ago, and the device was simply stunning under the sun. As we all know, pilots want to be able to read the screen under all sun conditions: sun in the front, in the back , upside or aside. Results in the past were quite disappointing: there were devices perfectly readable under sunlight when it was perpendicular from the back, like old PDAs from HP, but then they became all black when the light was in front of you.”
Click here to read the full review.

.

Software should be installed on a micro SD card. Once loaded with software the unit is a remarkable tactical flight computer for all gliding pilots. The unit comes with a bracket and suction mount and can easily fit into all paraglider flight decks as well as gilder cockpits.

.

The V2 uses the powerful SiRF III GPS engine and is equipped with BlueTooth, it makes use of a 10 pin Mini USB port to allow the use of two serial ports. The V2 will connect to a PC with the newest ActiveSync version 4.5.

.

Please note that SanDisk cards DO NOT work with the V2

.

Additional Pressure Sensor:

The inclusion of the internal pressure sensor has a short lead time of approx 2 weeks to due to the fabrication of the sensor to the V2; this additional feature is undertaken on a one to one basis and is not offered as standard. Please note that this pressure sensor does not act as a vario but only as an internal source of pressure altitude data.

.

Interface cables are also available from Glidertools and GliderGuider  and MillenAir (www.millenair.nl):

.

The package comes with:

USB Cable and 10-5 pin USB Cable, USB Cable, Suction mount, Bracket, Cigarette charger, 2 pin wall charger, Stylus and 2GB Micro SD card.
Download the Manual for the V2 Flight Instrument by VerticaSports

Specifications:

Dimensions (mm):
134 x 86 x 13 (WxHxD)
Battery:
Rechargeable LiOn, 3.7V, 1750mAh
Operating Time:
2.5 Hours
CPU:
Hisilicon K3 / 460 MHz
Weight (g):
182
SDRAM:
128 MB
NAND Flash Memory:
256 MB
Local FLASH Memory:
256 MB
Expansion Memory:
Micro SDCard (Max 32GB) – SanDisk not compatible
Operating System:
Windows Mobile Ver. 6.1
Operating Language:
English
Display Type:
5” TFT LCD, Sunlight Readable
Display Resolution:
480 x 272
Display Brightness:
800-1000 NITS
Internal GPS Engine:
SiRF Star III GDS3TW
GPS Sensitivity:
-147 dBm
GPS Channels:
20
Operating Temperature:
-20 to +50 deg. Centigrade
Network:
Bluetooth (BT)– with support for file transfer & SPP
USB:
USB 2.0 via 10 pin Mini B USB interface COM4 Reserved for the internal GPS Engine. COM7 Serial port – reserved for external data. COM8 Serial port – reserved for external data.
